30×40 First Floor House Plan with 3 Shops & 3BHK Layout | Mixed-Use Residential Commercial Design

30x40 mixed-use first floor house plan featuring three bedrooms, hall, kitchen, toilet, front commercial shops, central staircase, and internal passage. The plot measures 30 feet in width and 40 feet in depth. The front portion includes three shops, each approximately 7 feet wide and 9 feet deep, aligned along a 3.25-foot-wide front passage. A centrally located staircase provides upward access to upper floors. Behind the staircase, the residential section includes a hall measuring approximately 14x7.75 feet. Two bedrooms at the top measure about 10.5x11.5 feet each, while a larger bedroom on the right side measures approximately 14.5x10 feet. The kitchen is positioned at the top right corner measuring approximately 11.5x7 feet. A common toilet measuring approximately 7x6 feet is located on the left middle side. The layout clearly shows dimensions, wall thickness, door swings, and circulation paths.

Leave a Comment / By
30x40 mixed-use first floor house plan featuring three bedrooms, hall, kitchen, toilet, front commercial shops, central staircase, and internal passage. The plot measures 30 feet in width and 40 feet in depth. The front portion includes three shops, each approximately 7 feet wide and 9 feet deep, aligned along a 3.25-foot-wide front passage. A centrally located staircase provides upward access to upper floors. Behind the staircase, the residential section includes a hall measuring approximately 14x7.75 feet. Two bedrooms at the top measure about 10.5x11.5 feet each, while a larger bedroom on the right side measures approximately 14.5x10 feet. The kitchen is positioned at the top right corner measuring approximately 11.5x7 feet. A common toilet measuring approximately 7x6 feet is located on the left middle side. The layout clearly shows dimensions, wall thickness, door swings, and circulation paths.

30×40 First Floor House Plan with 3 Shops & 3BHK Layout | Mixed-Use Residential Commercial Design

₹0.00

Guaranteed Safe Checkout
somdn_product_page

Explore this practical and investment-friendly 30×40 first floor house plan that combines residential living with commercial shop space. Designed for a 30-foot-wide and 40-foot-deep plot, this layout maximizes land utilization by integrating three front-facing shops with a comfortable 3-bedroom residential unit.

The commercial portion includes three shops, each measuring approximately 7×9 feet, aligned along a 3.25-foot-wide front passage for easy customer access. This arrangement makes the design ideal for property owners looking to generate rental income while residing in the same building.

A centrally located staircase provides independent access to upper floors, ensuring smooth vertical circulation. The residential section behind the staircase includes three well-proportioned bedrooms, with two measuring approximately 10.5×11.5 feet and a larger 14.5×10 feet bedroom on the right side. The hall (approximately 14×7.75 feet) acts as the main living area, connecting to the kitchen and bedrooms efficiently.

The kitchen, positioned at the top right corner (approximately 11.5×7 feet), ensures functional workflow and ventilation. A common toilet (7×6 feet) is placed strategically for easy access.

This 30×40 mixed-use floor plan is ideal for urban plots, offering a balanced combination of residential comfort and commercial opportunity within optimized space planning.
