9.83X40 1BHK

This 9.83 ft front and 7.83 ft rear trapezoidal narrow plot 1BHK house plan is designed for compact 40 ft deep urban sites. The ground floor layout includes one bedroom at the rear, a centrally located toilet, an open hall with kitchen space, and a front staircase block for future vertical expansion. The design efficiently uses the elongated trapezoidal plot by placing service areas in the middle and maintaining privacy for the bedroom at the rear. The staircase at the entrance allows the possibility of constructing upper floors (G+1 or G+2) in the future. The open hall and kitchen layout maximizes usable space within the limited frontage. This plan is ideal for small families, rental units, or low-budget residential construction in dense city environments. Structurally, the layout can be executed using 9–10 inch RCC columns and beams to ensure safe load distribution. A practical and cost-effective solution for narrow residential plots.
