This detailed 90×150 ft plotting layout (actual measurement 90.75×150 ft) is designed for residential land development, small-scale township planning, and organized plotted schemes. The layout is divided into eight individual plots, each clearly labeled with plot numbers and katha area to make the land division easy for buyers, developers, and real estate planners.

At the top of the layout, a main road provides the primary access to the plotting site. From this main road, a wide internal road runs vertically down the middle of the site, giving direct access to all eight plots. This central-axis road layout is one of the most efficient ways to ensure each plot receives a clean approach and equal frontage.

Plots No. 1 and 2 are the largest, each measuring 1.5 katha, placed strategically at the top near the main road for premium accessibility. Plots No. 3, 4, 5, and 6 are 1 katha each, positioned on both sides of the internal road, offering balanced lot sizes ideal for residential homes. Plots No. 7 and 8, each 0.9 katha, provide slightly smaller yet very functional plot sizes suitable for compact homes, rental houses, or investment-friendly land parcels.

The plotting layout maintains equal 40 ft frontage for all plots, while the depth varies depending on the katha size. This uniform frontage ensures architectural harmony in future construction and improves property value. The internal road design also allows for proper movement of vehicles, utilities placement, and drainage planning.

This plotting design is ideal for:
– Individual residential land buyers
– Small real estate developers
– Housing project planning
– Gated community layouts
– Township or block development
– Investment plotting schemes

Overall, the 90×150 ft plotting plan delivers a clean, practical, and market-ready land division layout with excellent road connectivity, standardized plot dimensions, and clear zoning — perfect for residential development and real estate marketing.
