26×33 Mixed-Use Building Plan with 2 Front Shops, 2BHK House & Staircase Access

This 26 ft × 33 ft plot is designed as a smart mixed-use building combining commercial shops at the front and a residential unit at the rear.

At the front side facing the road, two shops are provided:

  • Shop 1: Approximately 10 ft × 10 ft

  • Shop 2: Approximately 7 ft × 10 ft

These shops are ideal for small retail stores, service outlets, medical shops, or offices.

On the front-left side, a 6-foot-wide staircase and parking area is provided. This staircase allows independent access to upper floors, making the design suitable for rental apartments or additional residential units above.

Behind the commercial section, the residential portion includes:

  • A central drawing room (approximately 12 ft × 8 ft)

  • A kitchen (approximately 6 ft × 5 ft)

  • Two bedrooms (each approximately 10 ft × 12 ft)

  • One centrally located common toilet

  • Another toilet near the living space

An OTS (open-to-sky) shaft of approximately 4 ft × 4 ft is provided at the rear center to ensure natural ventilation and light for the toilet and bedrooms.

This layout efficiently balances business and residential use within a compact urban plot.

Leave a Comment / By
26 feet by 33 feet mixed-use building floor plan featuring two commercial shops at the front and a 2BHK residential layout at the rear. The first shop measures approximately 10 feet by 10 feet, while the second shop measures approximately 7 feet by 10 feet. A 6-foot-wide staircase and parking area is positioned at the front-left corner, allowing independent access to upper floors. Behind the shops, a central drawing area measuring approximately 12 feet by 8 feet connects to the residential section. The kitchen measures approximately 6 feet by 5 feet. Two bedrooms measuring approximately 10 feet by 12 feet each are located at the rear. An OTS (open-to-sky) shaft measuring approximately 4 feet by 4 feet is provided for ventilation of the common toilet and bedrooms. One common toilet is centrally located, and another toilet is positioned near the living area. The layout efficiently combines commercial and residential use with vertical circulation.

26×33 Mixed-Use Building Plan with 2 Front Shops, 2BHK House & Staircase Access

₹0.00

Guaranteed Safe Checkout
somdn_product_page

Looking for a 26×33 mixed-use building plan with shops and residential space? This layout combines two commercial shops at the front with a 2BHK residential unit at the rear, making it ideal for property owners seeking rental income and home convenience.

The front section includes two shops measuring approximately 10 ft × 10 ft and 7 ft × 10 ft. These units are suitable for small businesses such as grocery stores, medical shops, salons, or offices.

A 6-foot-wide staircase is positioned on the front-left side, allowing independent access to upper floors. This makes the building suitable for rental flats or future vertical expansion without disturbing shop operations.

Behind the shops, the residential portion includes a drawing room (approximately 12 ft × 8 ft), a compact kitchen (6 ft × 5 ft), and two bedrooms measuring approximately 10 ft × 12 ft each.

The plan includes two toilets — one common centrally located and another near the living area. A 4 ft × 4 ft OTS (open-to-sky) shaft is provided for proper ventilation of toilets and bedrooms.

This 26×33 mixed-use building plan is ideal for urban plots where maximizing rental income and efficient land utilization are key priorities.
